If you’re using Homebrew, the script tools/macos-setup-brew.sh will intall the same tools and libraries from Homebrew. If an install package is not available or you have a reason not to use it (maybe because it’s simply too old), you can install that tool from source code. Ensure that the Wireshark Git Pre-Commit Hook is in the repository. To support my open-source work, consider adding me on Patreon. MacOS 10.15 Catalina Mostly-Automated Setup. An easy to refer to document for regularly setting up macOS 10.15 Catalina. The topic of recipe-based frequent fresh reinstalls of macOS is a controversial issue.
If you find yourself troubleshooting network issues, and you have to inspect individual packets, you need to use Wireshark. Wireshark is the de facto, go-to, you-need-to-know-how-to-use, application to capture and investigate network traffic.
Since Wireshark is the be-all-end-all tool for this job, let’s go over some basics – like where to download, how to capture network packets, how to use the Wireshark filters, and more.
Get the Free Pen Testing Active Directory Environments EBook
What is Wireshark?
Wireshark is an open-source network protocol analysis software program started by Gerald Combs in 1998. A global organization of network specialists and software developers support Wireshark and continue to make updates for new network technologies and encryption methods.
Wireshark is absolutely safe to use. Government agencies, corporations, non-profits, and educational institutions use Wireshark for troubleshooting and teaching purposes. There isn’t a better way to learn networking than to look at the traffic under the Wireshark microscope.
There are questions about the legality of Wireshark since it is a powerful packet sniffer. The Light side of the Force says that you should only use Wireshark on networks where you have permission to inspect network packets. Using Wireshark to look at packets without permission is a path to the Dark Side.
How does Wireshark work?
Wireshark is a packet sniffer and analysis tool. It captures network traffic on the local network and stores that data for offline analysis. Wireshark captures network traffic from Ethernet, Bluetooth, Wireless (IEEE.802.11), Token Ring, Frame Relay connections, and more.
Ed. Note: A “packet” is a single message from any network protocol (i.e., TCP, DNS, etc.)
Ed. Note 2: LAN traffic is in broadcast mode, meaning a single computer with Wireshark can see traffic between two other computers. If you want to see traffic to an external site, you need to capture the packets on the local computer.
Wireshark allows you to filter the log either before the capture starts or during analysis, so you can narrow down and zero into what you are looking for in the network trace. For example, you can set a filter to see TCP traffic between two IP addresses. You can set it only to show you the packets sent from one computer. The filters in Wireshark are one of the primary reasons it became the standard tool for packet analysis.
How to Download Wireshark
Downloading and installing Wireshark is easy. Step one is to check the official Wireshark Download page for the operating system you need. The basic version of Wireshark is free.
Wireshark for Windows
Wireshark comes in two flavors for Windows, 32 bit and 64 bit. Pick the correct version for your OS. The current release is 3.0.3 as of this writing. The installation is simple and shouldn’t cause any issues.
Wireshark for Mac
Wireshark is available on Mac as a Homebrew install.
To install Homebrew, you need to run this command at your Terminal prompt:
/usr/bin/ruby -e '$(curl -fsSL https://raw.githubusercontent.com/Homebrew/install/master/install)”
Once you have the Homebrew system in place, you can access several open-source projects for your Mac. To install Wireshark run this command from the Terminal:
brew install wireshark
Homebrew will download and install Wireshark and any dependencies so it will run correctly.
Wireshark for Linux
Installing Wireshark on Linux can be a little different depending on the Linux distribution. If you aren’t running one of the following distros, please double-check the commands.
Ubuntu
From a terminal prompt, run these commands:
sudo apt-get install wiresharksudo dpkg-reconfigure wireshark-commonsudo adduser $USER wireshark
Those commands download the package, update the package, and add user privileges to run Wireshark.
Red Hat Fedora
From a terminal prompt, run these commands:
sudo dnf install wireshark-qtsudo usermod -a -G wireshark username
The first command installs the GUI and CLI version of Wireshark, and the second adds permissions to use Wireshark.
Kali Linux
Wireshark is probably already installed! It’s part of the basic package. Check your menu to verify. It’s under the menu option “Sniffing & Spoofing.”
Data Packets on Wireshark
Now that we have Wireshark installed let’s go over how to enable the Wireshark packet sniffer and then analyze the network traffic.
Capturing Data Packets on Wireshark
When you open Wireshark, you see a screen that shows you a list of all of the network connections you can monitor. You also have a capture filter field, so you only capture the network traffic you want to see.
You can select one or more of the network interfaces using “shift left-click.” Once you have the network interface selected, you can start the capture, and there are several ways to do that.
Click the first button on the toolbar, titled “Start Capturing Packets.”
You can select the menu item Capture -> Start.
Or you could use the keystroke Control – E.
During the capture, Wireshark will show you the packets that it captures in real-time.
Once you have captured all the packets you need, you use the same buttons or menu options to stop the capture.
Best practice says that you should stop Wireshark packet capture before you do analysis.
Analyzing Data Packets on Wireshark
Wireshark shows you three different panes for inspecting packet data. The Packet List, the top pane, is a list of all the packets in the capture. When you click on a packet, the other two panes change to show you the details about the selected packet. You can also tell if the packet is part of a conversation. Here are some details about each column in the top pane:
- No.: This is the number order of the packet that got captured. The bracket indicates that this packet is part of a conversation.
- Time: This column shows you how long after you started the capture that this packet got captured. You can change this value in the Settings menu if you need something different displayed.
- Source: This is the address of the system that sent the packet.
- Destination: This is the address of the destination of that packet.
- Protocol: This is the type of packet, for example, TCP, DNS, DHCPv6, or ARP.
- Length: This column shows you the length of the packet in bytes.
- Info: This column shows you more information about the packet contents, and will vary depending on what kind of packet it is.
Packet Details, the middle pane, shows you as much readable information about the packet as possible, depending on what kind of packet it is. You can right-click and create filters based on the highlighted text in this field.
The bottom pane, Packet Bytes, displays the packet exactly as it got captured in hexadecimal.
When you are looking at a packet that is part of a conversation, you can right-click the packet and select Follow to see only the packets that are part of that conversation.
Wireshark Filters
One of the best features of Wireshark is the Wireshark Capture Filters and Wireshark Display Filters. Filters allow you to view the capture the way you need to see it so you can troubleshoot the issues at hand. Here are several filters to get you started.
Wireshark Capture Filters
Capture filters limit the captured packets by the filter. Meaning if the packets don’t match the filter, Wireshark won’t save them. Here are some examples of capture filters:
host IP-address: this filter limits the capture to traffic to and from the IP address
net 192.168.0.0/24: this filter captures all traffic on the subnet.
dst host IP-address: capture packets sent to the specified host.
port 53: capture traffic on port 53 only.
port not 53 and not arp: capture all traffic except DNS and ARP traffic
Wireshark Display Filters
Wireshark Display Filters change the view of the capture during analysis. After you have stopped the packet capture, you use display filters to narrow down the packets in the Packet List so you can troubleshoot your issue.
The most useful (in my experience) display filter is:
ip.srcIP-address and ip.dstIP-address
This filter shows you packets from one computer (ip.src) to another (ip.dst). You can also use ip.addr to show you packets to and from that IP. Here are some others:
tcp.port eq 25: This filter will show you all traffic on port 25, which is usually SMTP traffic.
icmp: This filter will show you only ICMP traffic in the capture, most likely they are pings.
ip.addr != IP_address: This filter shows you all traffic except the traffic to or from the specified computer.
Analysts even build filters to detect specific attacks, like this filter to detect the Sasser worm:
ls_ads.opnum0x09
Additional Wireshark Features
Beyond the capture and filtering, there are several other features in Wireshark that can make your life better.
Wireshark Colorization Options
You can setup Wireshark so it colors your packets in the Packet List according to the display filter, which allows you to emphasize the packets you want to highlight. Check out some examples here.
Wireshark Promiscuous Mode
By default, Wireshark only captures packets going to and from the computer where it runs. By checking the box to run Wireshark in Promiscuous Mode in the Capture Settings, you can capture most of the traffic on the LAN.
Wireshark Command Line
Wireshark does provide a Command Line Interface (CLI) if you operate a system without a GUI. Best practice would be to use the CLI to capture and save a log so you can review the log with the GUI.
Wireshark Commands
- wireshark : run Wireshark in GUI mode
- wireshark –h : show available command line parameters for Wireshark
- wireshark –a duration:300 –i eth1 –w wireshark. : capture traffic on the Ethernet interface 1 for 5 minutes. –a means automatically stop the capture, -i specifics which interface to capture
Metrics and Statistics
Under the Statistics menu item, you will find a plethora of options to show details about your capture.
Run Wireshark Brew Install
Capture File Properties:
Wireshark I/O Graph:
Additional Wireshark Resources and Tutorials
There are many tutorials and videos around that you show you how to use Wireshark for specific purposes. You should start on the main Wireshark website and move forward from there. You can find the official documentation and Wiki on that site.
Wireshark is a great network sniffer and analysis tool – however, in my opinion, it’s best used once you know what you are looking for. You aren’t going to use Wireshark to find a new problem. There is too much noise on the network. You need something like Varonis with Edge to make sense of the overall situation for you and point you to a threat to investigate, and then you use Wireshark to dig in deeper to understand exactly what is in the packets that are dangerous.
Brew Install Wireshark
For example, when Varonis Security Researchers discovered the norman cryptominer, they received an alert from Varonis pointing to suspicious network and file activity from several machines. During the analysis of the cryptominer, Varonis researchers used Wireshark to inspect network activities for some of the machines that were misbehaving. Wireshark showed the research team that a new cyptominer, norman, was actively communicating to command and control (C&C) servers using DuckDNS. The Varonis team was able to see all the IP addresses of the C&C servers the attackers used with Wireshark so the company could shut off communication and stopping the attack.
To see the Varonis team in action, sign up for a Live Cyber Attack Demo. Pick any time that works for you!
It can be difficult to trace network traffic from a Node.js application.Typically, folks will just instrument some logging to check that everything isworking as it is supposed to. Unfortunately, sometimes there are too manyabstractions or possible race conditions to accurately get a good trace. To getthe most objective possible trace of network traffic Wireshark can be used.
Wireshark is a network protocol analyzer that makes it extremely simple tocapture and trace network activity from any source on your computer. It also hastools built in to decrypt traffic like that of HTTPS (TLS / SSL).
Setup
Brew Wireshark Permission Denied
In the case of capturing HTTPS (TLS / SSL) traffic, there is some setup beforecapturing traffic. If all you need is to capture unencrypted HTTP, then skip tothe Wireshark installation, since Wireshark can do so out-of-the-box.
SSL key logging for HTTPS (TLS / SSL) decryption
If you'd like to decrypt HTTPS (TLS / SSL) you will need to set a path via anenvironmental variable to collect SSL keys for use in Wireshark. This sameenvironmental variable works for most browsers and some other applications aswell.
Set the path and file name to whatever you would like.
Node.js SSL key logging
Node.js v12.3.0 introduced a keylog API to store SSL keys, but it can beunwieldy to setup and integrate with existing libraries. It also does not workwith the SSLKEYLOGFILE environmental variable. Luckily, there is a simple wayto set up using an npm module: sslkeylog. sslkeylog sets up global hooksinto the https module to capture any SSL keys used which makes it therecommended way of capturing SSL keys. sslkeylog can be installed with npmlike below:
Once sslkeylog is installed, import it and active its hooks before making anyHTTP(S) calls. For example:
If you use TypeScript, you may need to include a declaration file like below:
Once capturing traffic is complete, you can remove all the code related to SSLkey logging.
Wireshark
First things first, you must install Wireshark program. On macOS you can usebrew to not only install the CLI, but the UI app as well:
For Wireshark to be able to decrypt HTTPS (TLS / SSL) traffic it needs to readthe SSL Key log generated by Node.js or other applications. To configure thisfor Wireshark, open up the application and then open the preferences forWireshark. Once the preferences are open, open the 'Protocols' dropdown in theleft sidebar menu listing and scroll down to 'TLS', then click on it. On olderversions of Wireshark, look for 'SSL' instead of 'TLS'. Once the settings for'TLS' (or 'SSL' for older versions) is open, look for the '(Pre)-Master-Secretlog filename' setting and set the path to the same one that was configured abovevia the SSLKEYLOGFILE environmental variable. You might need to create anempty file at the path given.
Capturing traffic
Now that you are all setup, you can begin capturing traffic. Open up Wiresharkand select the capture interface, which for macOS is usually en0 (Wi-Fi).
Once capturing has begun you should start to see logs of all sorts of trafficto be listed, unless you are not connected to the internet.
This traffic can be overwhelming and mostly unrelated to Node.js or theapplication you are trying to inspect. This where filters come in handy.
For example, to filter requests on a domain:
Or to filter on a certain IP address:
Filters can also be combined with conditional operators && and ||.
Once capturing has begun, you can start your app up as normal and try to causenetwork activity that is in need of being traced.
Hopefully, with a combination with the filters you will be able to find theexact requests and responses you are looking for. If you find either a requestor a response you can right click on a line item and select 'Follow > HTTPStream' to see the both of the request and response.
Additionally, you can save any traffic captured for later use or to send topeers for inspection.
